You need a reliable way to programmatically check port congestion for Kaohsiung (TWKHH) to drive transportation operations and schedules. By the end of this guide, you’ll be able to call a real HTTP endpoint, authenticate with an API key, parse the JSON envelope, and extract the congestion level, date, and ratio vs. baseline in Python.

What this API provides (and what it does not)

The FreightPulse port congestion endpoint returns a structured, lagged congestion signal for specific ports derived from IMF PortWatch. It is suitable for dashboards, alerts, and planning workflows where day-level updates suffice.

Illustration: API to Check Congestion at Kaohsiung

Endpoint and parameters for Kaohsiung (TWKHH)

Use a GET request against this endpoint, specifying the port code TWKHH:

GET /api/v1/port-congestion?port=TWKHH

The header X-API-Key should carry your API key. If you do not have a key, you can still query as a guest within the daily limit. For production use and higher volume, register for an API key.

Copy-paste cURL you can run now

curl -H "X-API-Key: YOUR_API_KEY" "https://freightpulsehq.com/api/v1/port-congestion?port=TWKHH"

Official JSON response example for Kaohsiung

{
"success": true,
"data": {
"results": [
{
"port": "Kaohsiung",
"locode": "TW KHH",
"country": "Taiwan Province of China",
"congestion": "moderate",
"as_of": "2026-10-16",
"metrics": {
"recent_avg_portcalls_per_day": 30,
"baseline_avg_portcalls_per_day": 27.7,
"ratio_vs_baseline": 1.08
}
}
],
"global_summary": {
"ports_high_congestion": 0,
"ports_moderate": 1,
"ports_low": 0
},
"meta": {
"source": "IMF PortWatch (portwatch.imf.org) - UN Global Platform AIS data",
"data_lag_days": "~6-7 (daily updates, not real-time)",
"methodology": "congestion level is an approximation: last 7 days' avg port calls vs 90-day baseline for the same port. Does not measure vessel wait/anchorage time."
}
},
"meta": {
"request_id": "d6b19527-8f54-4ddd-bd5e-069531828ecf"
}
}

Fields you will likely use in transportation workflows:

Python guide: calling the endpoint and parsing congestion for TWKHH

This walkthrough shows how to make a single request for Kaohsiung and safely extract congestion, as_of, and ratio_vs_baseline. It also includes simple checks for the JSON envelope and empty results.

Install and import

Use the built-in libraries and requests. If you don’t have requests:

python -m pip install requests

Code sample

import os
import requests
from typing import Optional, Tuple

API_URL = "https://freightpulsehq.com/api/v1/port-congestion"
PORT_CODE = "TWKHH"

def fetch_kaohsiung_congestion(api_key: Optional[str]) -> Tuple[Optional[str], Optional[str], Optional[float]]:
headers = {}
if api_key:
headers["X-API-Key"] = api_key

params = {"port": PORT_CODE}
resp = requests.get(API_URL, headers=headers, params=params, timeout=20)
resp.raise_for_status()
payload = resp.json()

# Basic envelope validation
if not isinstance(payload, dict) or not payload.get("success"):
raise RuntimeError("Unexpected API envelope or success=false")

data = payload.get("data", {})
results = data.get("results", [])

if not results:
# No data returned for this port
return None, None, None

# Assume the first result corresponds to the requested port
rec = results[0]
congestion = rec.get("congestion")
as_of = rec.get("as_of")

# metrics may be nested
metrics = rec.get("metrics", {})
ratio_vs_baseline = metrics.get("ratio_vs_baseline")

return congestion, as_of, ratio_vs_baseline

if __name__ == "__main__":
# Read from environment for convenience; falls back to guest if missing
api_key = os.environ.get("FREIGHTPULSE_API_KEY")
try:
congestion, as_of, ratio = fetch_kaohsiung_congestion(api_key)
if congestion is None:
print("No congestion record returned for TWKHH.")
else:
print(f"Kaohsiung (TWKHH) congestion: {congestion} as of {as_of} (ratio_vs_baseline={ratio})")
except Exception as e:
print(f"Error: {e}")

How to think about the signal for transportation use cases

The congestion category is a compact summary appropriate for routing decisions and stakeholder updates. The underlying ratio_vs_baseline is more granular and helps you set automated thresholds. For example, you could treat ratios above 1.1 as “elevated demand/throughput” and below 0.9 as “below baseline” when prioritizing port calls or scheduling inland drayage.

Important: the metric is about port call counts, not anchorage dwell or berth waiting times. It is most reliable for medium-horizon planning where daily updates suffice and finely grained intra-day AIS movements are not required.

Operational details that save time

Common integration patterns for Kaohsiung (TWKHH)

Testing and validation checklist

Security, keys, and environments

Put the X-API-Key in a secure secret store and inject at runtime (e.g., environment variables). Rotate keys as part of your normal incident procedures. For local testing or simple prototypes, guest access can suffice, but moving to key-based auth is recommended for stability and observability.

Linking back to the official docs and registration

For endpoint details and any additional parameters, see the Documentation. To get a production API key, create an account here: Register.

FAQ

Is this data real-time AIS?
No. It is derived from IMF PortWatch and updates daily with a ~6–7 day lag. It should not be used as live anchorage or berth wait-time data.

Which fields should I store for automation?
Store congestion, as_of, and metrics.ratio_vs_baseline at a minimum. Optionally store recent_avg_portcalls_per_day and baseline_avg_portcalls_per_day for auditability.

What happens if there are multiple results in data.results?
The query is for a single port, so typically you’ll get one primary record. If you extend usage later, handle arrays robustly and select by locode or port name as needed.

Can I use this to quote today’s freight rates?
No. This endpoint does not provide pricing and should not be used to quote a USD fare or rate.

How should I handle guest rate limits?
Cache the response for 12–24 hours and share it across services. If you need higher volume or multiple environments, use an API key via the X-API-Key header.

Next step

Set up a daily job that calls GET /api/v1/port-congestion?port=TWKHH, parse congestion, as_of, and ratio_vs_baseline, and expose it in your transportation dashboard with the lag disclaimer. When you’re ready for production keys and higher limits, create an account via Register, and consult the Documentation for any advanced options.
